MIX15L Vacuum Mixer‑Defoamer_15L Ultra‑large Capacity Industrial‑grade Vacuum Defoaming Equipment‑SIENOX

Why Must Microbubbles in Materials Be Eliminated?

Residual micro‑bubbles in large‑volume high‑viscosity materials directly affect product yield and performance stability.

Recommend application cases for SIENOX SIE‑MIX15L Vacuum Mixer‑Defoamer.

3D Printing Industry

Bubbles in large‑size 3D‑printing resin slurries create inter‑layer voids, weakening interlayer bonding and mechanical strength of printed parts. Bubbles in ceramic 3D‑printing slurries generate internal pores after sintering, impairing dimensional accuracy and density. Bubble issues are amplified in mass‑material production; uneven bubble distribution across batches causes quality fluctuations among multiple printed parts.

Polyurethane Industry

Bubbles in cast polyurethane elastomers degrade mechanical properties including elasticity, wear resistance and load‑bearing capacity. Uneven bubble distribution in polyurethane foams produces density gradients and deteriorates thermal‑insulation and cushioning performance. In mass polyurethane production, bubbles directly harm product consistency and yield. 15L large‑volume processing reduces batch‑split cycles and minimizes batch‑to‑batch deviation.

Aerospace & Defense Industry

Bubbles in aerospace composite resin matrices form stress‑concentration spots and reduce interlaminar shear strength and anti‑fatigue performance of composites. Bubbles in aerospace thermal‑conductive potting compounds lower heat‑dissipation efficiency and reliability of electronic devices. The aerospace‑defense sector allows extremely low material‑defect tolerance. Residual micro‑bubbles may trigger critical‑component failure, hence strict requirements for defoaming processes.

✨ Traditional Defoaming Dilemmas: Manual stirring for large-capacity and high-viscosity materials features low efficiency and uneven mixing. Conventional small-capacity equipment requires repeated batch processing, making it difficult to guarantee batch consistency. Static defoaming delivers limited results on high-viscosity materials with extremely long processing time. The large-capacity vacuum mixing and defoaming technology applies -98kPa vacuum negative pressure during planetary stirring. It processes 15L materials in a single run, reducing batch operations and ensuring consistent quality for mass production.

Why Choose MIX15L

Specially built for heavy‑industrial mass‑production vacuum defoaming with extra‑large capacity

15L High‑capacity Design

Standard dual‑station loading of 15L per cycle. Low‑speed high‑torque transmission adapts to ultra‑high‑viscosity heavy slurries. 0‑30L expansion customization is available to meet factory 24‑hour continuous batch‑processing requirements.

Planetary Transmission System

Reinforced frame and heavy‑duty gear structure with switchable planetary speed ratio. Strong centrifugal force disperses high‑fill powders to reduce material sedimentation and agglomeration, supporting long‑term non‑stop operation.

Production‑line‑grade Intelligent Control

Multi‑level permission touch screen stores multiple mass‑production recipes. Compatible with factory MES system for full‑process data logging. Equipped with multi‑fold safety protection for overload, vacuum and door interlock, suitable for standardized industrial production lines.

✨ When vacuum defoaming is required and production volume reaches the 5000 mL level, the MIX5000 serves as a pilot‑scale option for small‑to‑medium batches within the planetary vacuum mixer‑defoamer series.

Working Principle

Adopt collaborative process of planetary revolution, container rotation and high‑vacuum sealing

Planetary Revolution: High‑power main shaft drives the turntable for low‑speed high‑torque revolution, generating steady continuous centrifugal force. It pushes high‑viscosity and high‑filler materials to adhere evenly against vessel walls and suppress sedimentation and delamination of heavy‑weight powders.

Container Rotation: Material buckets rotate synchronously in reverse direction, generating extensive fluid shear inside containers. No impeller contacts materials to minimize metallic impurity contamination, ideal for heavy high‑solid‑content slurries.

High‑flow Vacuum Defoaming: Large chamber paired with high‑flow vacuum pump builds rapid and stable negative pressure. Deep‑seated micro‑bubbles inside materials rise and separate under pressure difference. Mixing and defoaming proceed simultaneously to eliminate separate defoaming steps, matching the rhythm of continuous mass production.

Technical Specifications

Rigorous Equipment Performance Index Data Alignment

Model	SIE‑MIX15L
Mixing Capacity	0‑15L (standard vessel) * Customizable
Vessel Type	Tubes / Jars / Cups; adapters for syringes and cartridges available
Number of Vessels	1 or 2 jars (user‑selectable)
Max Speed	0‑600 RPM (stepless adjustable)
Revolution / Rotation Ratio	Fixed planetary ratio
Vacuum Degree	Standard: ‑98 kPa / Optional: ‑100 kPa
Control System	Touch screen, stores up to 100 recipe sets
Power Supply	220V, 50/60Hz (110V US/JP standard customizable)
Dimensions(W×D×H)	1735 × 1560 × 965 mm
Net Weight	830kg
Certifications	CE, ISO9001, RoHS Compliance

我们的合作伙伴

深受全球知名工业制造集群及前沿高校实验室信赖

合作伙伴展示

FAQ 您关心的问题

为您解答关于产品性能及日常工艺选型中的常见疑问

真空脱泡搅拌机是什么？用于哪些行业？

真空脱泡搅拌机是在真空环境下同步完成搅拌与脱泡的设备，脱泡同时混料，避免二次气泡混入，常用于环氧树脂、硅胶、AB 胶等高粘度材料的混料脱泡处理，广泛应用于新能源电池、半导体封装、LED、电子灌封、胶粘剂等行业。
广州施诺斯主要生产哪些设备？

主要产品包括搅拌脱泡机、真空脱泡搅拌机、真空脱泡机、高压脱泡机、真空搅拌机、实验室均质机、三辊研磨机、三维混粉机，以及点胶机、分装机等配套设备和夹具、搅拌罐、针筒等辅品耗材。
源头厂家采购脱泡设备有什么优势？

源头厂家直供可省去中间环节，价格更透明，同时能提供参数定制、来料试机、工艺验证等服务，售后响应更直接。
搅拌脱泡机的工作原理？

施诺斯设备采用行星式混合原理：料罐在自转的同时绕公转轴公转，物料在罐内随之翻动混合，同时抽真空脱泡。整个过程设备不设搅拌桨，搅拌部件不接触物料，不会引入金属异物，混合均匀不分层。
为什么选择施诺斯？

施诺斯（SIENOX）是广州施诺斯科技股份有限公司旗下品牌，2014 年成立，专注脱泡机与搅拌机的研发与制造，团队自 2006 年起从事真空搅拌脱泡设备研发。设备采用非接触式设计，不设搅拌桨，行星式公转加自转运动辅以真空系统，高效除泡，混合均匀不分层。公司产品涵盖搅拌脱泡机、真空脱泡搅拌机、真空脱泡机、高压脱泡机、真空搅拌机、实验室均质机、三辊研磨机、三维混粉机，以及点胶机、分装机等配套设备和夹具、搅拌罐、针筒等辅品耗材，广泛应用于新能源、半导体、LED、电子灌封、胶粘剂、涂料、油墨等行业。通过 ISO9001、CE 认证，拥有 30 余项专利，服务富士康、比亚迪、清华大学等企业与科研院所。

Technical Specification List

Full‑line standardized specifications for accurate process evaluation and equipment selection

Model	SIE‑MIX5000	SIE‑MIX15L	SIE‑MIX20L
Mixing Capacity	0‑5000 mL (standard vessel) * Customizable	0‑15L (standard vessel) * Customizable	0‑20L (standard vessel) * Customizable
Vessel Type	Tubes / Jars / Cups; adapters for syringes and cartridges available	Tubes / Jars / Cups; adapters for syringes and cartridges available	Tubes / Jars / Cups; adapters for syringes and cartridges available
Number of Vessels	1 or 2 jars (user‑selectable)	1 or 2 jars (user‑selectable)	1 or 2 jars (user‑selectable)
Max Speed	0‑1200 RPM (stepless adjustable)	0‑600 RPM (stepless adjustable)	0‑500 RPM (stepless adjustable)
Revolution / Rotation Ratio	Fixed planetary ratio	Fixed planetary ratio	Fixed planetary ratio
Vacuum Degree	Standard: ‑98 kPa / Optional: ‑100 kPa	Standard: ‑98 kPa / Optional: ‑100 kPa	Standard: ‑98 kPa / Optional: ‑100 kPa
Control System	Touch screen, stores up to 100 recipe sets	Touch screen, stores up to 100 recipe sets	Touch screen, stores up to 100 recipe sets
Power Supply	220V, 50/60Hz (110V US/JP standard customizable)	220V, 50/60Hz (110V US/JP standard customizable)	220V, 50/60Hz (110V US/JP standard customizable)
Dimensions(W×D×H)	1370 ×1130 × 965mm	1735 × 1560 × 965 mm	1870 × 1380 × 1160 mm
Net Weight	550kg	830 kg	900 kg
Certifications	CE	CE	CE

***Above are typical models only. Customized solutions are available upon customer requirements.
