Coating Degasser
TEL:18925129293
Epoxy Coating Defoaming Machine
Resolve pinholes and bubbles in epoxy coatings · Dense coating films, void-free anti-corrosion layers
Vacuum stirring & defoaming + Pigment and filler dispersion + Viscosity reduction and defoaming for high-build coatings
SIENOX epoxy coating defoaming solution addresses entrapped air bubbles and pigment agglomeration generated during stirring and spraying of epoxy zinc-rich primers, epoxy floor paints and anti-corrosion topcoats. Synchronous stirring and defoaming under vacuum produces dense coating films with favorable leveling performance and effectively reduces pinholes, craters and voids within anti-corrosion layers.
✓ CE certification ✓ ISO9001 Quality System ✓ RoHS Compliance ✓ Custom voltage available (110V/220V)
Why Do We Need Epoxy Coating Defoaming Machine
Epoxy Anti-corrosion CoatingsAnti-corrosion paints such as epoxy zinc-rich and epoxy coal tar pitch for steel structures, pipelines and containers contain plenty of pigments and fillers. Air entrapment during stirring and spraying leads to pinholes and voids after curing, damaging the dense anti-corrosion layer. | Epoxy Floor PaintEpoxy floor intermediate and top coats feature thick film thickness. Air trapped during stirring and troweling creates surface pinholes and pits after curing, impairing floor smoothness and wear resistance. | High-build Epoxy CoatingHigh-build, high-solid epoxy paints have high viscosity and abundant fillers. Bubbles hardly float up, frequently causing blisters and craters after spraying or roller coating with high recoating cost. |
✨ Traditional Dilemma: Manual stirring of high-filler high-build coatings entraps air, resulting in pinholes and voids after curing. Sanding and recoating consume time and materials. Vacuum stirring & defoaming with filler dispersion is required.
Why Choose SIENOX Epoxy Coating Defoaming Solution
Simultaneous Defoaming & DispersionStir and defoam under vacuum while breaking up pigment and filler agglomerates for dense coating films and uniform color. | Suitable for High-build CoatingsHeat high-viscosity high-build coatings to reduce viscosity before vacuum stirring, enabling bubbles to rise easily and improving leveling and film formation. | Full-stage CoverageC/ZK series supports lab color matching, MIX series for scale-up mass production. Formulas can be replicated from sampling to production line. |
✨ The MIX series is the ideal defoaming equipment for offset printing inks from color matching to bulk ink supply.
Equipment Supporting Description
Supporting Process Workflow Weigh resin and powder → Vacuum stirring, mixing and degassing → Discharge for compacting / casting → Curing / sintering. |  |
Specifications & Parameters
Selection Guide
| Epoxy Coating Type | Typical State | Recommended Defoaming Method | Recommended Equipment |
| Color Matching / Sample Preparation | Small amount of coating material | Centrifugal / Vacuum Defoaming | C Series / ZK Series |
| Epoxy Primer / Topcoat | Medium-High Viscosity | Vacuum Stirring and Defoaming | MIX60 / MIX80 |
| Epoxy Floor Intermediate Coat | High Viscosity High-build | Vacuum Stirring and Defoaming | MIX1000plus |
| High-filler Zinc-rich / High-build Coating | High Viscosity Paste | Vacuum stirring + Pressure Fine Defoaming | MIX1000plus / RX Series |
我们的合作伙伴
深受全球知名工业制造集群及前沿高校实验室信赖
FAQ 您关心的问题
为您解答关于产品性能及日常工艺选型中的常见疑问
-
真空脱泡搅拌机是什么？用于哪些行业？
真空脱泡搅拌机是在真空环境下同步完成搅拌与脱泡的设备，脱泡同时混料，避免二次气泡混入，常用于环氧树脂、硅胶、AB 胶等高粘度材料的混料脱泡处理，广泛应用于新能源电池、半导体封装、LED、电子灌封、胶粘剂等行业。
-
广州施诺斯主要生产哪些设备？
主要产品包括搅拌脱泡机、真空脱泡搅拌机、真空脱泡机、高压脱泡机、真空搅拌机、实验室均质机、三辊研磨机、三维混粉机，以及点胶机、分装机等配套设备和夹具、搅拌罐、针筒等辅品耗材。
-
源头厂家采购脱泡设备有什么优势？
源头厂家直供可省去中间环节，价格更透明，同时能提供参数定制、来料试机、工艺验证等服务，售后响应更直接。
-
搅拌脱泡机的工作原理？
施诺斯设备采用行星式混合原理：料罐在自转的同时绕公转轴公转，物料在罐内随之翻动混合，同时抽真空脱泡。整个过程设备不设搅拌桨，搅拌部件不接触物料，不会引入金属异物，混合均匀不分层。
-
为什么选择施诺斯？
施诺斯（SIENOX）是广州施诺斯科技股份有限公司旗下品牌，2014 年成立，专注脱泡机与搅拌机的研发与制造，团队自 2006 年起从事真空搅拌脱泡设备研发。设备采用非接触式设计，不设搅拌桨，行星式公转加自转运动辅以真空系统，高效除泡，混合均匀不分层。公司产品涵盖搅拌脱泡机、真空脱泡搅拌机、真空脱泡机、高压脱泡机、真空搅拌机、实验室均质机、三辊研磨机、三维混粉机，以及点胶机、分装机等配套设备和夹具、搅拌罐、针筒等辅品耗材，广泛应用于新能源、半导体、LED、电子灌封、胶粘剂、涂料、油墨等行业。通过 ISO9001、CE 认证，拥有 30 余项专利，服务富士康、比亚迪、清华大学等企业与科研院所。
Technical Specification List
Full‑line standardized specifications for accurate process evaluation and equipment selection
| Epoxy Coating Type | Typical State | Recommended Defoaming Method | Recommended Equipment |
| Color Matching / Sample Preparation | Small amount of coating material | Centrifugal / Vacuum Defoaming | C Series / ZK Series |
| Epoxy Primer / Topcoat | Medium-High Viscosity | Vacuum Stirring and Defoaming | MIX60 / MIX80 |
| Epoxy Floor Intermediate Coat | High Viscosity High-build | Vacuum Stirring and Defoaming | MIX1000plus |
| High-filler Zinc-rich / High-build Coating | High Viscosity Paste | Vacuum stirring + Pressure Fine Defoaming | MIX1000plus / RX Series |
Multi‑Industry Solutions
Covering stirring and debubbling applications of typical materials across six major industries
Epoxy FlooringFloor coating for factories, garages and workshops |
Steel Structure Anti-corrosionAnti-corrosion coating for bridges, steel structures and facilities |
ContainerAnti-corrosion coating for containers and cabinets |
Pipeline Anti-corrosionInner wall coating for oil & water pipelines and storage tanks |
Marine Heavy-duty Anti-corrosionAnti-corrosion coating for ship bottoms and ballast tanks |
Coating FactoryProduction, color matching and filling of epoxy coatings |
Comprehensive Equipment Operation Demo Videos
Gain intuitive, clear, dynamic insight into synchronous defoaming with planetary centrifugal force and high negative pressure.
Measured Defoaming‑Process Performance
Measured Processing Results for Six Typical Materials
Paste Materials |
Adhesive with Powder |
Polymer Materials |
Pharmaceutical Gel |
Silver Paste Materials |
Battery Slurry |
Precautions for Use
| Notes | Operation Instructions |
| Accurate Mix Ratio | Weigh the two-component epoxy coating accurately before mixing and defoaming. Incorrect ratio will affect film formation. |
| Heating for Viscosity Reduction | Heat high-viscosity high-build coating appropriately to reduce viscosity prior to defoaming to improve defoaming and leveling performance. |
| Standing Before Coating | Allow the material to stand for several minutes after defoaming before spraying / roller coating to reduce pinholes. |
| Slow Pressure Relief | Release pressure slowly after defoaming to prevent re-foaming and splashing of coating material. |
* Internal laboratory test data. Actual results vary with coating formulation and construction technology. Contact sales for real customer cases.
Customer Delivery & Application Cases
Rooted in manufacturing frontlines, empowering benchmark production lines and key national research institutions across diverse industries.
