SIENOX Fully‑automatic Dispenser SIE‑302
Multi‑head Parallel for Higher Efficiency · Flexible Multi‑variety Production for Medium‑sized Products
High‑efficiency Multi‑head Dispensing + 600×600mm Working Travel + Flexible Multi‑variant Changeover
SIENOX SIE‑302 automatic dispenser features four‑axis linkage and precise glue control. 600×600×100mm working travel supports single‑head / multi‑head modes with 20kg max load and ±0.02mm repeat accuracy. Compatible with various fluids such as silicone, sealant and hot‑melt glue, ideal for multi‑variety production of medium‑sized products.
✓ ISO9001 Quality System ✓ RoHS Compliance ✓ Customizable Voltage (110V/220V)
Why Precision Dispensing Is Required
Manual dispensing relies on operator experience, resulting in unstable glue volume control. Issues such as glue accumulation, leakage and stringing frequently occur, making yield hard to guarantee.
Growing Encapsulation Demands for LED Lighting ModulesProcesses including LED encapsulation, module potting and lens bonding require precise glue application at multiple positions on LED modules. Encapsulation materials such as silicone and potting compound feature high viscosity. Manual dispensing struggles to control glue volume and position, which easily causes uneven potting or air bubbles. The 600×600mm working travel of SIE‑302 fits LED module dimensions. Multi‑head mode enables simultaneous dispensing on multiple modules to improve encapsulation efficiency. ±0.02mm accuracy ensures accurate potting position, compatible with LED encapsulation materials such as silicone, potting adhesive and speaker adhesive. | Sealing & Dispensing for Automotive Electronic ComponentsAutomotive electronic processes such as lamp sealing, ECU potting and sensor fixing impose strict requirements on dispensing consistency and sealing performance. Dozens of dispensing procedures are involved in one vehicle, and different adhesives (sealant, hot‑melt adhesive, structural adhesive) are applied for various components. Manual operation cannot guarantee consistent quality. SIE‑302 supports multi‑variety program storage for quick changeover by recalling corresponding programs. One machine handles dispensing for multiple automotive electronic parts. Multi‑head mode boosts mass‑production efficiency, and ±0.02mm accuracy ensures reliable sealing quality. | Coating for Housings & Wiring Harnesses in Home Appliance ManufacturingProcesses such as home‑appliance housing sealing, wiring harness fixing and shock‑absorbing coating require large‑area and multi‑point glue application. Materials including hot‑melt adhesive, foam adhesive and sealant need uniform coating on housing seams and wiring harness joints. The 600×600mm working travel of SIE‑302 covers dimensions of most home‑appliance products. Four‑axis linkage supports coating on curved and vertical surfaces, and multi‑head mode accelerates tact time for mass‑production home‑appliance lines. |
✨ Dilemmas of traditional dispensing: Manual dispensing has low efficiency, poor consistency and unstable yield. Semi‑automatic dispensers only perform planar dispensing and cannot handle 3D curved surfaces. Single‑head dispensers deliver limited efficiency and cannot satisfy mass‑production tact time. Conventional dispensers require complex programming with long changeover time, not suitable for multi‑variety production.
Why Choose SIE‑302
Solve Dispenser Selection Pain Points for Medium‑sized Products
Flexible & Efficient Single‑head / Multi‑head Dual ModesSupports both single‑head and multi‑head working modes for flexible adaptation to various production scenarios. Single‑head mode prioritizes accuracy for multi‑variant small‑batch production; multi‑head mode boosts productivity with simultaneous operation of multiple dispensing heads for low‑variant mass production. Use single‑head mode for program debugging in R&D phase and switch to multi‑head mode for mass production. One machine covers the whole process from development to mass production. Max load 20kg, compatible with medium‑sized products and fixtures. | Full‑coverage 600×600mm Working Travel600×600×100mm working travel fits medium‑sized products such as LED modules, automotive electronic components, home appliances and acoustic devices. Compact footprint for standard workshop deployment. Four‑axis linkage enables dispensing on 3D, inclined and curved surfaces, meeting diverse dispensing path requirements. | Program Storage for Fast Multi‑variant SwitchoverSupports on‑site programming via teach pendant and CAD / CORELDRAW programming on PC. Stored programs can be recalled directly without reprogramming for quick product changeover. Ideal for flexible multi‑variety production and reduces downtime for changeover. Timing‑belt plus guide‑rail transmission, moving speed 0.1‑500mm/s, balancing efficiency and stability. |
✨ If you require dispensing for medium‑sized products, multi‑head efficiency improvement or flexible multi‑variant production changeover, SIE‑302 is your ideal choice.
Product Features
Based on planetary motion principle
Four‑axis Linkage Multi‑dimensional Motion Four‑axis linkage design supports forward‑backward and left‑right movement as well as dispensing on 3D, inclined and curved surfaces. It can rapidly perform dotting, line drawing, circle drawing and dispensing / coating / spraying of various irregular patterns on product surfaces, outer walls, vertical planes and gaps. Precise Glue Control System Equipped with glue delay and advance glue‑off functions to precisely control glue output timing and volume. It delivers uniform glue spraying and effectively avoids glue accumulation, cured dead glue, stringing, leakage and dripping. Repeat positioning accuracy: ±0.02mm. Dual‑mode Programming Supports on‑site programming via teach pendant and PC‑based programming with CAD / CORELDRAW software. Storable and recallable programs enable fast changeover, suitable for multi‑variety small‑batch production. Timing‑belt & Guide‑rail Transmission Adopts timing‑belt plus guide‑rail transmission. Travel speed adjustable from 0.1 to 500mm/s, balancing high‑speed efficiency and motion stability. Three Working Modes Three working modes: dot dispensing, spray dispensing and coating to meet diverse process requirements. Controlled by hand‑held controller or PC for flexible operation. Wide Compatibility for Liquids Compatible with various solvents, adhesives, paints and chemical materials, including dozens of industrial fluids such as UV glue, red glue, solder paste, silver glue, epoxy glue, instant glue and sealant. |  |
Quick View of Technical Specifications
Complete Technical Specifications Overview, Customizable on Demand
| Model | SIE‑302 |
| Working Range | 600×600×100mm |
| Control Mode | Handle / Computer |
| Nozzle Mode | Single / Multi Nozzles |
| Working Mode | Dispensing / Spraying / Coating |
| Glue Delay | Available |
| Advance Glue Shutoff | Available |
| Max Load (kg) | 10 |
| Moving Speed (mm/s) | 0.1~500 |
| Repeat Accuracy (mm) | ±0.02 |
| Overall Dimension (W×D×H) | 700×800×500mm |
我们的合作伙伴
深受全球知名工业制造集群及前沿高校实验室信赖
FAQ 您关心的问题
为您解答关于产品性能及日常工艺选型中的常见疑问
-
真空脱泡搅拌机是什么？用于哪些行业？
真空脱泡搅拌机是在真空环境下同步完成搅拌与脱泡的设备，脱泡同时混料，避免二次气泡混入，常用于环氧树脂、硅胶、AB 胶等高粘度材料的混料脱泡处理，广泛应用于新能源电池、半导体封装、LED、电子灌封、胶粘剂等行业。
-
广州施诺斯主要生产哪些设备？
主要产品包括搅拌脱泡机、真空脱泡搅拌机、真空脱泡机、高压脱泡机、真空搅拌机、实验室均质机、三辊研磨机、三维混粉机，以及点胶机、分装机等配套设备和夹具、搅拌罐、针筒等辅品耗材。
-
源头厂家采购脱泡设备有什么优势？
源头厂家直供可省去中间环节，价格更透明，同时能提供参数定制、来料试机、工艺验证等服务，售后响应更直接。
-
搅拌脱泡机的工作原理？
施诺斯设备采用行星式混合原理：料罐在自转的同时绕公转轴公转，物料在罐内随之翻动混合，同时抽真空脱泡。整个过程设备不设搅拌桨，搅拌部件不接触物料，不会引入金属异物，混合均匀不分层。
-
为什么选择施诺斯？
施诺斯（SIENOX）是广州施诺斯科技股份有限公司旗下品牌，2014 年成立，专注脱泡机与搅拌机的研发与制造，团队自 2006 年起从事真空搅拌脱泡设备研发。设备采用非接触式设计，不设搅拌桨，行星式公转加自转运动辅以真空系统，高效除泡，混合均匀不分层。公司产品涵盖搅拌脱泡机、真空脱泡搅拌机、真空脱泡机、高压脱泡机、真空搅拌机、实验室均质机、三辊研磨机、三维混粉机，以及点胶机、分装机等配套设备和夹具、搅拌罐、针筒等辅品耗材，广泛应用于新能源、半导体、LED、电子灌封、胶粘剂、涂料、油墨等行业。通过 ISO9001、CE 认证，拥有 30 余项专利，服务富士康、比亚迪、清华大学等企业与科研院所。
Technical Specification List
Full‑line standardized specifications for accurate process evaluation and equipment selection
| Model | SIE‑301 | SIE‑302 | SIE‑303 |
| Working Range | 400×400×100mm | 600×600×100mm | 1000×1000×200mm |
| Control Mode | Handle / Computer | Handle / Computer | Handle / Computer |
| Nozzle Mode | Single Nozzle | Single / Multi Nozzles | Single / Multi Nozzles |
| Working Mode | Dispensing / Spraying / Coating | Dispensing / Spraying / Coating | Dispensing / Spraying / Coating |
| Glue Delay | Available | Available | Available |
| Advance Glue Shutoff | Available | Available | Available |
| Max Load (kg) | 10 | 10 | 10 |
| Moving Speed (mm/s) | 0.1~500 | 0.1~500 | 0.1~500 |
| Repeat Accuracy (mm) | ±0.02 | ±0.02 | ±0.02 |
| Overall Dimension (W×D×H) | 500×600×500mm | 700×800×500mm | 1300×1100×1600mm |
Multi‑Industry Solutions
Covering stirring and debubbling applications of typical materials across six major industries
Adhesive R&DEpoxy structural adhesive, sealant, hot‑melt adhesive, pressure‑sensitive adhesive, modified adhesive |
Precision Electronic AssemblyUnderfill adhesive, conductive adhesive, die attach adhesive, dispensing adhesive, chip bonding adhesive |
BiosensorEncapsulation adhesive, reagent immobilization material, microfluidic bonding adhesive, biocompatible adhesive, sensor sealant |
Microelectronic PackagingPackaging epoxy adhesive, molding compound, lead bonding adhesive, substrate bonding adhesive, passivation layer material |
Functional CoatingHydrophobic coating, conductive coating, insulating coating, anti‑corrosion coating, wear‑resistant coating |
Electronic PasteSilver paste, copper paste, carbon paste, resistance paste, dielectric paste |
Comprehensive Equipment Operation Demo Videos
Gain intuitive, clear, dynamic insight into synchronous defoaming with planetary centrifugal force and high negative pressure.
Measured Defoaming‑Process Performance
Measured Processing Results for Six Typical Materials
Paste‑like Materials |
Glue with Powder |
Polymer Materials |
Pharmaceutical Gels |
Silver Paste Materials |
Battery Slurry |
Usage Precautions
Comparison of Material State Before and After Three-Roll Milling
| Precautions | Description |
| Liquid Viscosity Matching | Adjust dispensing parameters (speed / delay / glue shut‑off time) for liquids of different viscosities. Trial adjustment is recommended for first‑time use. |
| Needle Selection | Select proper needle specifications according to glue volume and liquid viscosity. Needle inner diameter affects dispensing performance. |
| Cleaning & Maintenance | Regularly clean dispensing valve and needle to prevent blockage caused by cured glue. Flush pipelines when changing liquids. |
| Program Management | Build product program library marked with product names and parameters for quick recall. |
| Environmental Requirements | Keep working environment clean to avoid dust affecting dispensing quality. UV glue shall be stored away from light. |
| Safe Operation | Do not place hands into working area while equipment is running. Press stop button in case of emergency. |
* Internal laboratory test data. Actual improvement varies with material formula. Contact sales for real‑world customer cases.
