Homogenizing Emulsifier SIE‑MIX90


Pilot‑scale Dual‑can Synchronous Emulsification · One Unit Covers Formula Validation to Small‑batch Production

1000 mL Pilot‑scale Dual‑can Synchronous + Precise Emulsification + Seamless Transition from Formula to Small‑batch Production

SIE‑MIX90 Homogenizing Emulsifier is a dual‑can emulsification & dispersion equipment for pilot‑scale applications. Processing volume ranges from 0‑1000 mL with adjustable speed 0‑2000 rpm. Stable operation at fixed speed ratio and ‑98 kPa vacuum degree, suitable for formula validation and small‑batch production in cosmetics, chemical raw materials, food and other industries.

✓ CE Certification  ✓ ISO9001 Quality System ✓ RoHS Compliance ✓ Custom Voltage Available (110V/220V)

在线留言 免费寄样测试 工程师热线:189-2512-9293

Why Do You Need a Homogenizing Emulsifier

Precise processing volume for pilot‑scale requirements

Cosmetics & Daily‑care Industry

For creams, lotions, mask liquids and other products, batches of several hundred milliliters to one liter are often required for transition from pilot‑scale to mass production. Formulators verify emulsification stability, adjust texture and confirm process parameters at this stage.

Chemical Raw Material Industry

Pilot‑scale processing of adhesives, coating additives, resin emulsions requires stable and controllable emulsification conditions. High raw‑material cost makes over‑sized pilot batches wasteful, while undersized batches cannot validate processes properly.

Food Industry

Pilot‑scale processing for sauces, flavored emulsions and edible emulsions demands both hygiene standards and good emulsifying performance. The vacuum function of MIX90 realizes simultaneous defoaming during emulsification to avoid bubbles impairing taste and shelf life. Dual‑can synchronous processing enables parallel validation of different flavor formulas to boost R&D efficiency.

✨ Traditional Dilemma: The awkward pilot‑scale stage. Lab equipment requires multiple runs for 1L samples with potential batch‑to‑batch parameter deviations; production‑line units start at dozens of liters, where hundreds of milliliters cannot even submerge the rotor‑stator head. An emulsifier with pilot‑targeted processing capacity ensures reliable formula validation.

Why Choose MIX90

Solve Core Pain Points of Emulsification & Dispersion at Pilot‑scale Stage

Precise 0‑1000 mL Pilot‑scale Coverage

Processing volume 0‑1000 mL, accurately matching typical batch demands at pilot‑scale stage. Pilot tests for creams of several hundred milliliters and lotion scale‑up within 1 L can be finished in one run. No repeated multi‑batch runs for small batches, nor raw material waste from oversized equipment.

Stable Fixed‑speed‑ratio Operation with Reproducible Parameters

Fixed revolution‑to‑rotation speed ratio ensures stable and reliable performance. Verified emulsification parameters can be precisely reproduced in later batches — vital for pilot‑scale work, since parameter consistency directly determines smooth scale‑up from formula to process.

Synchronous Dual‑tank Design for Doubled Efficiency

2‑tank configuration processes two samples at the same time. Pilot‑scale work often compares different formulas or process parameters. Synchronous dual‑tank enables one‑run comparative tests under identical conditions for comparable data and higher R&D efficiency.

✨ If your pilot‑scale processing volume falls within 0‑1000 mL and you require stable reproducible emulsification parameters plus dual‑tank parallel efficiency

Product Features

0‑1000 mL Pilot‑scale Processing Volume

Processing volume 0‑1000 mL, accurately covering typical pilot‑scale batches. It handles formula validation of several hundred milliliters and small‑batch production up to nearly 1 L with one single unit. It prevents efficiency loss from repeated batches on small‑size equipment and raw‑material waste caused by under‑filled large‑size equipment.

Precisely Adjustable Speed: 0‑2000 rpm

0‑2000 rpm adjustable speed with stable fixed‑speed‑ratio operation. Suitable rotating speed can be selected according to material viscosity and emulsification requirements, covering gentle emulsification to high‑intensity dispersion. Stable and reproducible parameters enable pilot‑scale results to guide mass‑production directly.

Synchronous Dual‑tank Design

1×2‑tank configuration for simultaneous emulsification of two samples. Formula comparison and parameter verification in pilot‑scale can be conducted in parallel under identical conditions to guarantee consistent data and double R&D efficiency. Tubes, tanks and cups are all compatible.

Integrated Vacuum Defoaming

‑98 kPa vacuum degree enables simultaneous defoaming during emulsification. For bubble‑prone products such as creams and lotions, emulsification and defoaming are finished in one step to reduce subsequent procedures and deliver more stable product quality.

Optional Heating / Cooling
Optional heating or cooling module for emulsification processes requiring temperature control. Heating melting for cream emulsification and low‑temperature emulsification for certain bio‑active ingredients are supported, enhancing equipment adaptability.
Extended Network‑access Function
Optional network‑access function realizes operation data recording and remote monitoring. For industries requiring process‑parameter traceability such as pharmaceutical and food industries, network‑access function helps standardize production‑record management.


Technical Specifications

Complete Technical Specifications Overview, Customizable on Demand

ModelSIE‑MIX90
Mixing Volume0–1000 mL (standard container) * Larger volume customizable
Vessel TypeTest tube / tank / cup; adapters for syringes & cartridges supported
Vessel Quantity1 or 2 tanks (user‑selectable)
Max Speed0 – 2000 RPM (stepless adjustable)
Revolution / Rotation RatioFixed planetary ratio
Vacuum DegreeStandard: –98 kPa / Optional: –100 kPa
Control SystemTouch screen, stores 100 sets of recipe parameters
Power Supply220V, 50/60Hz (110V US/Japan standard customizable)
Overall Dimension(W×D×H)610 × 560 × 780 mm
Net Weight153 kg
Certifications CE, ISO9001, RoHS Compliance

我们的合作伙伴

深受全球知名工业制造集群及前沿高校实验室信赖

合作伙伴展示

FAQ 您关心的问题

为您解答关于产品性能及日常工艺选型中的常见疑问

  • 真空脱泡搅拌机是什么?用于哪些行业?

    真空脱泡搅拌机是在真空环境下同步完成搅拌与脱泡的设备,脱泡同时混料,避免二次气泡混入,常用于环氧树脂、硅胶、AB 胶等高粘度材料的混料脱泡处理,广泛应用于新能源电池、半导体封装、LED、电子灌封、胶粘剂等行业。

  • 广州施诺斯主要生产哪些设备?

    主要产品包括搅拌脱泡机、真空脱泡搅拌机、真空脱泡机、高压脱泡机、真空搅拌机、实验室均质机、三辊研磨机、三维混粉机,以及点胶机、分装机等配套设备和夹具、搅拌罐、针筒等辅品耗材。

  • 源头厂家采购脱泡设备有什么优势?

    源头厂家直供可省去中间环节,价格更透明,同时能提供参数定制、来料试机、工艺验证等服务,售后响应更直接。

  • 搅拌脱泡机的工作原理?

    施诺斯设备采用行星式混合原理:料罐在自转的同时绕公转轴公转,物料在罐内随之翻动混合,同时抽真空脱泡。整个过程设备不设搅拌桨,搅拌部件不接触物料,不会引入金属异物,混合均匀不分层。

  • 为什么选择施诺斯?

    施诺斯(SIENOX)是广州施诺斯科技股份有限公司旗下品牌,2014 年成立,专注脱泡机与搅拌机的研发与制造,团队自 2006 年起从事真空搅拌脱泡设备研发。设备采用非接触式设计,不设搅拌桨,行星式公转加自转运动辅以真空系统,高效除泡,混合均匀不分层。公司产品涵盖搅拌脱泡机、真空脱泡搅拌机、真空脱泡机、高压脱泡机、真空搅拌机、实验室均质机、三辊研磨机、三维混粉机,以及点胶机、分装机等配套设备和夹具、搅拌罐、针筒等辅品耗材,广泛应用于新能源、半导体、LED、电子灌封、胶粘剂、涂料、油墨等行业。通过 ISO9001、CE 认证,拥有 30 余项专利,服务富士康、比亚迪、清华大学等企业与科研院所。

Technical Specification List

Full‑line standardized specifications for accurate process evaluation and equipment selection

ModelSIE‑MIX60SIE‑MIXF301SIE‑MIX90
Mixing Volume0–300 mL (standard container) * Customizable0–300 mL (standard container) * Customizable0–1000 mL (standard container) * Customizable
Vessel TypeTest tube / tank / cup; adapters for syringes & cartridges supportedTest tube / tank / cup; adapters for syringes & cartridges supportedTest tube / tank / cup; adapters for syringes & cartridges supported
Vessel Quantity1  or 2 tanks (user‑selectable)1  or 2 tanks (user‑selectable)1  or 2 tanks (user‑selectable)
Max Speed0 – 3000 RPM (stepless adjustable)0 – 2000 RPM (stepless adjustable)0 – 2000 RPM (stepless adjustable)
Revolution / Rotation RatioFixed planetary ratioFreely adjustableFixed planetary ratio
Vacuum DegreeStandard: –98 kPa / Optional: –100 kPaStandard: –98 kPa / Optional: –100 kPaStandard: –98 kPa / Optional: –100 kPa
Control SystemTouch screen, stores 100 sets of recipe parametersTouch screen, stores 100 sets of recipe parametersTouch screen, stores 100 sets of recipe parameters
Power Supply220V, 50/60Hz (110V US/Japan standard customizable)220V, 50/60Hz (110V US/Japan standard customizable)220V, 50/60Hz (110V US/Japan standard customizable)
Overall Dimension(W×D×H)510 × 430 × 500 mm510 × 430 × 500 mm610 × 560 × 780 mm
Net Weight95 kg115 kg153 kg

*** The above are typical models only. Customized solutions are available upon customer requirements.


Multi‑Industry Solutions

Only partial application scenarios are shown. Free sample testing with your materials is welcome.


SMT Electronic Manufacturing

Solder paste, red glue, flux, underfill adhesive, SMT adhesive

Automotive Electronics.jpg

Automobile Manufacturing

Structural adhesive, sealant, thermal‑conductive silicone, primer, anaerobic adhesive

New Energy.jpg

Photovoltaic Manufacturing

Silver paste, aluminum paste, EVA film adhesive, silicone sealant, conductive adhesive

Printing & Packaging.jpg

Printing & Packaging

UV ink, water‑based ink, varnish, laminating adhesive, screen‑printing ink


Cosmetics & Daily‑care

Lotion, cream, gel, foundation, sunscreen


Ceramic Processing

Alumina slurry, zirconia slurry, ceramic glaze, electronic ceramic slurry, ceramic binder


Comprehensive Equipment Operation Demo Videos

Gain intuitive, clear, dynamic insight into synchronous defoaming with planetary centrifugal force and high negative pressure.

Measured Defoaming‑Process Performance

Actual Stirring & Defoaming Performance of Typical Materials

Lubricant Mixing & Defoaming.jpg

Lubricant

Potting Adhesive Defoaming.jpg

Potting Adhesive

Powder‑Adhesive Mixing & Defoaming.jpg

Powder + Adhesive

AB Glue Mixing & Defoaming.jpg

AB Glue

LED Materials.jpg

LED Materials

Epoxy Resin & Powder Mixing & Defoaming.jpg

Epoxy Resin + Powder


Measured Data Comparison

Material Defoaming Effect Comparison Before & After

Material TypeCondition Before TreatmentAfter MIX90 Treatment
Epoxy Resin (50,000cps)Visible bubbles, internal voids after curingFully bubble‑free & transparent, 22% higher mechanical strength
Conductive Silver PasteFiller sedimentation, unstable resistivityUniform filler dispersion, 40% lower resistivity
Lithium‑battery SlurryCoating pinholes, high electrode defect rateDense coating, 15% higher cell energy density

* Internal lab test data. Actual improvement varies with material formula. Contact sales for real‑world customer cases.

Customer Delivery & Application Cases

Rooted in manufacturing frontlines, empowering benchmark production lines and key national research institutions across diverse industries.



Stirring‑Defoaming Solution for Glue Materials in Consumer‑Electronics Industry



Vacuum Defoaming Solution for Consumer Electronics Adhesives



Industrial University Solves Bubble Challenges of Coating‑Film Materials with SIENOX Defoaming Machine
