SIENOX Centrifugal Defoamer SIE‑VH960
960mL Large‑Volume Single‑Cup Defoaming · Industrial‑Grade Stable Frame for Long‑Hour Operation
Standard 960mL×4 pcs + 0‑2000rpm Stepless Adjustment + Non‑Contact Centrifugal Defoaming
SIE‑VH960 centrifugal defoamer comes with standard 960mL×4‑piece configuration and 0‑2000rpm adjustable speed. Non‑contact centrifugal defoaming keeps material chemical properties unchanged, ideal for large‑volume single‑cup defoaming in electronics & semiconductor, adhesives, new energy and other industries.
✓ Patented Design ✓ FCC Certification ✓ ISO9001 Quality System ✓ 304 Stainless‑Steel Cabinet ✓ 20‑Year Original Manufacturer
Why Must Microbubbles in Materials Be Eliminated?
Micro‑bubbles remaining in single materials impair end‑product quality
Component Packaging IndustryResidual bubbles in underfill adhesive cause chip packaging voids, stress concentration and poor reliability. Centrifugal defoaming separates bubbles non‑contact merely by centrifugal force without impurities, suitable for large‑volume single‑cup packaging adhesive defoaming. | Fine Chemical IndustryBubbles in mold silicone trigger vulcanization defects, surface pores and reduced molding accuracy. Non‑contact defoaming proceeds inside sealed containers without stirrer contact, ideal for large‑volume adhesive pre‑treatment. | New Energy IndustryBubbles in PV conductive silver paste impair grid‑line printing quality, contact resistance and photoelectric conversion efficiency. Non‑contact centrifugal defoaming preserves paste chemical properties, suitable for PV auxiliary material defoaming. |
✨ Traditional Defoaming Pain Points: Static defoaming delivers limited performance for medium‑high viscosity materials. Manual stirring fails to eliminate deep‑seated bubbles, and contact‑type equipment may alter material properties. The centrifugal defoaming solution separates bubbles via non‑contact centrifugal force, and its large‑volume single‑cup setup adapts to medium‑high viscosity materials.
Why Choose SIE‑VH960
Three Core Advantages Cover Large‑Volume Single‑Cup Defoaming Requirements
960mL Large‑Volume Single CupMax 960mL per cup for large‑volume single‑cup defoaming of medium‑high viscosity materials. Large‑volume configuration reduces batch cycles and improves single‑run defoaming efficiency. | 32‑piece Processing CapacitySupports both large‑volume and high‑throughput processing modes. Flexible container setup adapts to varied batch requirements for R&D and production‑line applications. | Stable Batch OperationRobust frame ensures stable high‑speed operation with low vibration and noise. Industrial‑grade construction supports long‑duration continuous running to meet production‑line defoaming demands. |
✨ VH960 suits large-volume single-cup defoaming and industrial processing for medium and high viscosity materials.
Working Principle
High‑speed rotation generates centrifugal force, and gravity assists bubble escape. Materials complete non‑contact defoaming inside sealed containers.
Step 1: High-speed centrifugal separation. Set speed and time via control panel. Centrifugal force generated by high rotation separates bubbles from materials. Step 2: Gravity-driven escape. Gravity pulls materials downward while bubbles rise to the surface and escape. Step 3: Non-contact purity preservation. Materials rotate inside sealed syringes without mixing blades contact, leaving chemical properties unchanged. Three simple steps: Centrifugal Separation → Gravity Escape → Non-contact Purity Preservation. Defoaming finished in one cycle. |  |
Technical Specifications
Complete Technical Specifications Overview, Customizable on Demand
| Equipment Model | SIE‑VH960 |
| Mixing Capacity | 30 / 55 / 75 / … / 960 cc (Customizable) |
| Standard Configuration | 960mL × 4 pcs |
| Number of Containers | 32 pcs (User‑selectable) |
| Max Rotation Speed | 0 – 2000 RPM (Stepless adjustable) |
| Technical Principle | Centrifugal Defoaming |
| Container Type | Test tubes / Jars / Cups; Supports adapters for syringes and cartridges |
| Control System | Touch screen, stores up to 100 sets of recipe parameters |
| Power Supply | 220V, 50/60Hz (110V US/Japan standard customizable) |
| Overall Dimension(W×D×H) | 980 × 735 × 490 mm |
| Net Weight | Approx. 235 kg |
| Certifications | FCC, ISO9001, RoHS Compliance |
我们的合作伙伴
深受全球知名工业制造集群及前沿高校实验室信赖
FAQ 您关心的问题
为您解答关于产品性能及日常工艺选型中的常见疑问
-
真空脱泡搅拌机是什么？用于哪些行业？
真空脱泡搅拌机是在真空环境下同步完成搅拌与脱泡的设备，脱泡同时混料，避免二次气泡混入，常用于环氧树脂、硅胶、AB 胶等高粘度材料的混料脱泡处理，广泛应用于新能源电池、半导体封装、LED、电子灌封、胶粘剂等行业。
-
广州施诺斯主要生产哪些设备？
主要产品包括搅拌脱泡机、真空脱泡搅拌机、真空脱泡机、高压脱泡机、真空搅拌机、实验室均质机、三辊研磨机、三维混粉机，以及点胶机、分装机等配套设备和夹具、搅拌罐、针筒等辅品耗材。
-
源头厂家采购脱泡设备有什么优势？
源头厂家直供可省去中间环节，价格更透明，同时能提供参数定制、来料试机、工艺验证等服务，售后响应更直接。
-
搅拌脱泡机的工作原理？
施诺斯设备采用行星式混合原理：料罐在自转的同时绕公转轴公转，物料在罐内随之翻动混合，同时抽真空脱泡。整个过程设备不设搅拌桨，搅拌部件不接触物料，不会引入金属异物，混合均匀不分层。
-
为什么选择施诺斯？
施诺斯（SIENOX）是广州施诺斯科技股份有限公司旗下品牌，2014 年成立，专注脱泡机与搅拌机的研发与制造，团队自 2006 年起从事真空搅拌脱泡设备研发。设备采用非接触式设计，不设搅拌桨，行星式公转加自转运动辅以真空系统，高效除泡，混合均匀不分层。公司产品涵盖搅拌脱泡机、真空脱泡搅拌机、真空脱泡机、高压脱泡机、真空搅拌机、实验室均质机、三辊研磨机、三维混粉机，以及点胶机、分装机等配套设备和夹具、搅拌罐、针筒等辅品耗材，广泛应用于新能源、半导体、LED、电子灌封、胶粘剂、涂料、油墨等行业。通过 ISO9001、CE 认证，拥有 30 余项专利，服务富士康、比亚迪、清华大学等企业与科研院所。
Technical Specification List
Complete Technical Specifications Overview, Customizable on Demand
| Equipment Model | SIE‑VH350 | SIE‑VH960 | SIE‑VH2600 |
| Mixing Capacity | 30 / 55 / 75 / … / 300 cc (Customizable) | 30 / 55 / 75 / … / 960 cc (Customizable) | 30 / 55 / 75 / … / 2600 cc (Customizable) |
| Standard Configuration | 300CC × 4 pcs | 960mL × 4 pcs | 2600CC × 4 pcs |
| Maximum Number of Containers | 16 pcs | 32 pcs | 4 pcs |
| Max Rotation Speed | 0 – 2000 RPM (Stepless adjustable) | 0 – 2000 RPM (Stepless adjustable) | 0 – 1500 RPM (Stepless adjustable) |
| Technical Principle | Centrifugal Defoaming | Centrifugal Defoaming | Centrifugal Defoaming |
| Container Type | Tubes / Jars / Cups | Tubes / Jars / Cups | Tubes / Jars / Cups |
| Control System | Touch screen, stores up to 100 sets of recipe parameters | Touch screen, stores up to 100 sets of recipe parameters | Touch screen, stores up to 100 sets of recipe parameters |
| Power Supply | 220V, 50/60Hz (110V US/Japan standard customizable) | 220V, 50/60Hz (110V US/Japan standard customizable) | 220V, 50/60Hz (110V US/Japan standard customizable) |
| Overall Dimension(W×D×H) | 700 × 635 × 470 mm | 980 × 735 × 490 mm | 1250 × 920 × 550 mm |
| Net Weight | 150 kg | 235 kg | 380 kg |
| Certifications | FCC | FCC | FCC |
*** The above are typical models only. Customized solutions are available according to customer requirements.
Multi‑Industry Solutions
Covers centrifugal defoaming applications for typical materials across six major industries
AdhesivesPolyurethane sealant, one‑component silicone, acrylic adhesive, mold silicone |
Advanced Material R&DNano‑dispersion, ceramic slurry, reagent gel, laboratory compounded resin |
Medical ConsumablesMedical‑grade silicone, dental resin, biological gel, diagnostic reagent paste |
Optoelectronic DisplayOptical clear adhesive, touch‑screen silver paste, frame sealing silicone, backlight filling paste |  New Energy IndustryCell thermal conductive gel, battery module sealant, PV frame silicone, PV conductive silver paste |
Automotive ElectronicsVehicle‑mounted PCB potting compound, headlight encapsulation silicone, wire harness sealant, automotive thermal paste |
Comprehensive Equipment Operation Demo Videos
Gain intuitive, clear, dynamic insight into synchronous defoaming with planetary centrifugal force and high negative pressure.
Actual‑test Performance Demonstration
Lab Sample Actual Test Results
Gel |
Epoxy Resin |
Adhesive Materials |
Potting Compound |
Silver Paste Materials |
Adhesive |
Actual‑test Effect Comparison
Comparison of Material Condition Before and After Centrifugal Defoaming
Material Type | Condition Before Treatment | After VH960 Treatment |
Underfill Adhesive | Dense bubbles inside adhesive, packaging void rate approx. 6%, poor reliability | Bubbles eliminated, packaging void rate below 1%, improved reliability |
Mold Silicone | Numerous bubbles in silicone, vulcanization porosity approx. 7%, poor mold‑replication accuracy | Bubbles eliminated, vulcanization porosity below 2%, stable mold‑replication accuracy |
PV Conductive Silver Paste | Abundant bubbles in paste, grid‑line breakage rate approx. 5%, resistance fluctuation | Bubbles eliminated, grid‑line breakage rate below 1%, stable resistance |
* Internal laboratory test data. Actual improvement varies with material formulation. Contact sales for real‑world customer cases.
Customer Delivery & Application Cases
Rooted in manufacturing frontlines, empowering benchmark production lines and key national research institutions across diverse industries.
