Pressure Defoaming Machine SIE-RX4-600
Fast Pressure Rise in Small Chamber · Three Modes for Flexible R&D Sample Switching
φ400 Small Chamber 5-Minute Fast Pressure Rise + Three Pressure & Heating Modes Flexible Switching + Precision Filter Prevents Sample Secondary Contamination
Schnos SIE-RX4-600 Pressure Defoaming Machine, φ400×600mm cylindrical chamber with approximately 75L capacity, pressure rises to 0.6MPa in 5 minutes. Three working modes available, SMC digital pressure gauge accuracy ±0.01MPa, Omron PID temperature control accuracy ±1.0°C. Utilizes pressure and temperature to remove bubbles generated during the lamination process and enhance adhesion between materials.
✓ ISO9001 Quality System ✓ RoHS Compliant ✓ Custom Voltage Supported (110V/220V)
Why Must Microbubbles in Materials Be Eliminated?
Residual micro‑bubbles degrade end‑product quality directly
LCD Polarizer Lamination IndustryDuring the lamination of LCD polarizers with glass substrates, residual bubbles in OCA optical adhesive cause uneven light transmission and display haze, affecting screen display quality. Pressure defoaming compresses and dissolves bubbles through pressure, while temperature reduces OCA adhesive viscosity to assist bubble expulsion. The φ400 small chamber is suitable for sample lamination defoaming of small-size polarizers during the R&D stage, enabling rapid verification of process parameters. | Electronic Component Packaging IndustryBubbles in electronic component packaging adhesive cause voids in the packaging layer, and moisture intrusion leads to device failure, requiring repeated process parameter adjustment during the R&D stage. The three working modes of pressure defoaming allow selection of pressurize-first-then-heat or simultaneous heating and pressurization based on packaging adhesive characteristics. The small chamber's rapid pressure rise shortens the prototyping cycle, helping R&D teams quickly determine the packaging defoaming process solution. | Medical Device IndustryBubbles in medical device bonding and lamination affect biocompatibility and structural strength, requiring small-batch verification of defoaming effectiveness during the prototyping stage. The pressure defoaming precision filter prevents secondary contamination of products, the φ400 chamber is suitable for sample lamination defoaming of small-size medical devices, and the audible-visual-light alarm ensures safe and controllable prototyping processes. |
✨ The dilemma of traditional defoaming: during the R&D prototyping stage, there is a lack of professional pressure defoaming equipment. Relying on standing still to wait for bubbles to escape naturally takes a long time and has low efficiency; ordinary ovens only heat without pressurizing, making it difficult to expel bubbles from the lamination surface; inaccurate temperature control causes large variations in OCA adhesive fluidity, making process parameters difficult to reproduce stably.
Why Choose SIE-RX4-600
Address the pain points of efficiency and quality in the R&D trial‑production phase from three dimensions: rapid pressure rise, flexible modes, and clean trial‑production.
Small‑chamber Rapid Pressure RiseThe φ400×600 mm cylindrical chamber has a volume of approximately 75 L. It reaches 0.6 MPa within 5 minutes, completes pressure relief in 2‑3 minutes, and enables fast cycle turnover of 35‑40 minutes per cycle. Thanks to fast pressure rise and drop in the small chamber, process parameters can be iterated rapidly during R&D trial‑production. Multiple sets of conditional tests can be finished within one day to shorten the R&D cycle. | Flexible Switching Among Three ModesThree working modes are available: A. Pressurize first, then heat up; B. Heat up and pressurize simultaneously; C. Heat up first, then pressurize. Different materials respond differently to pressure and temperature. The three modes can be flexibly selected according to material properties. Parameters controlled by the microcomputer can be stored and reproduced to assist R&D teams in identifying feasible process solutions. | Anti‑pollution by Precision FilterInlet air passes through a precision filter before entering the chamber, preventing dust and impurities in the air from contaminating trial‑production samples. Samples in R&D trial‑production are high‑value and low‑volume; a single contamination incident may waste the entire batch. Precision filtration ensures a clean trial‑production environment and improves trial‑production success rates. |
✨ If your scenarios include R&D trial‑production, small‑sample lamination verification and process‑parameter debugging, the rapid pressure rise of the RX4‑600 small chamber and flexible switching among three modes enable you to achieve rapid iteration.
Working Principle
Remove bubbles generated during lamination by pressure and temperature to enhance bonding strength between different materials.
Step 1: Pressurization and Heating (Three‑mode Optional) Step 2: Pressure‑holding Defoaming Step 3: Pressure Relief and Stabilization Three simple steps: Pressurization & Heating → Pressure‑holding Defoaming → Pressure Relief & Stabilization, to eliminate bonding bubbles and strengthen adhesive force. |  |
Technical Specifications
Complete Technical Specifications Overview, Customizable on Demand
| Equipment Model | SIE‑RX4‑600 |
| Working Chamber Size | φ400×600mm (Cylindrical) |
| Effective Volume | Approx. 75L |
| Working Pressure | 0~0.8MPa (Standard), 0~2.5MPa (Optional) |
| Working Temperature | Ambient ~80℃ (Standard), Ambient ~180℃ (Optional) |
| Heating Method | Resistive Heating |
| Working Modes | A. Pressurize first then heat up B. Simultaneous heating and pressurization C. Heat up first then pressurize |
| Control Mode | Microcomputer Control |
| Vessel Material | S30408 Stainless Steel or Carbon Steel |
| Overall Dimension(W×D×H) | Approx. 700×900×1300mm (Subject to actual product) |
| Net Weight | 200 kg |
| Certifications | ISO9001, RoHS Compliance |
我们的合作伙伴
深受全球知名工业制造集群及前沿高校实验室信赖
FAQ 您关心的问题
为您解答关于产品性能及日常工艺选型中的常见疑问
-
真空脱泡搅拌机是什么？用于哪些行业？
真空脱泡搅拌机是在真空环境下同步完成搅拌与脱泡的设备，脱泡同时混料，避免二次气泡混入，常用于环氧树脂、硅胶、AB 胶等高粘度材料的混料脱泡处理，广泛应用于新能源电池、半导体封装、LED、电子灌封、胶粘剂等行业。
-
广州施诺斯主要生产哪些设备？
主要产品包括搅拌脱泡机、真空脱泡搅拌机、真空脱泡机、高压脱泡机、真空搅拌机、实验室均质机、三辊研磨机、三维混粉机，以及点胶机、分装机等配套设备和夹具、搅拌罐、针筒等辅品耗材。
-
源头厂家采购脱泡设备有什么优势？
源头厂家直供可省去中间环节，价格更透明，同时能提供参数定制、来料试机、工艺验证等服务，售后响应更直接。
-
搅拌脱泡机的工作原理？
施诺斯设备采用行星式混合原理：料罐在自转的同时绕公转轴公转，物料在罐内随之翻动混合，同时抽真空脱泡。整个过程设备不设搅拌桨，搅拌部件不接触物料，不会引入金属异物，混合均匀不分层。
-
为什么选择施诺斯？
施诺斯（SIENOX）是广州施诺斯科技股份有限公司旗下品牌，2014 年成立，专注脱泡机与搅拌机的研发与制造，团队自 2006 年起从事真空搅拌脱泡设备研发。设备采用非接触式设计，不设搅拌桨，行星式公转加自转运动辅以真空系统，高效除泡，混合均匀不分层。公司产品涵盖搅拌脱泡机、真空脱泡搅拌机、真空脱泡机、高压脱泡机、真空搅拌机、实验室均质机、三辊研磨机、三维混粉机，以及点胶机、分装机等配套设备和夹具、搅拌罐、针筒等辅品耗材，广泛应用于新能源、半导体、LED、电子灌封、胶粘剂、涂料、油墨等行业。通过 ISO9001、CE 认证，拥有 30 余项专利，服务富士康、比亚迪、清华大学等企业与科研院所。
Multi‑Model Specification Comparison Table
Compare Models in the Same Series for Accurate Selection
| Equipment Model | SIE‑RX4‑600 | SIE‑RX6‑900 | SIE‑RX8‑1200 |
| Working Chamber Size | φ400×600mm | φ600×900mm | φ800×1200mm |
| Effective Volume | 75L | 255L | 600L |
| Pressure Range | 0~2.5MPa(Optional) | 0~2.5MPa(Optional) | 0~2.5MPa(Optional) |
| Temperature Range | Ambient ~180℃(Optional) | Ambient ~180℃(Optional) | Ambient ~180℃(Optional) |
| Pressure Accuracy | ±0.01MPa | ±0.01MPa | ±0.01MPa |
| Temperature Control Accuracy | ±1.0℃ | ±1.0℃ | ±1.0℃ |
| Power Supply | 220V, 50/60Hz (110V US‑JP standard customizable) | 220V, 50/60Hz (110V US‑JP standard customizable) | 220V, 50/60Hz (110V US‑JP standard customizable) |
| Overall Dimension(W×D×H) | 510 × 430 × 500 mm | 610 × 560 × 780 mm | 610 × 560 × 780 mm |
| Net Weight | 95 kg | 153 kg | 163 kg |
***The above are typical models only. Customized solutions are available according to customer requirements.
Multi‑Industry Solutions
Covering stirring and debubbling applications of typical materials across six major industries
LCD Polarizer LaminationSmall‑size polarizer OCA optical adhesive, lamination adhesive for LCD glass substrate |
Electronic Component EncapsulationComponent encapsulant, chip potting adhesive |
Medical DevicesMedical bonding adhesive, medical device lamination adhesive |
LED EncapsulationLED encapsulant, phosphor paste |
Fine ChemicalsFine chemical materials, nano‑powders |
New Energy MaterialsR&D samples of new energy materials, small‑lot battery slurry |
Comprehensive Equipment Operation Demo Videos
Gain intuitive, clear, dynamic insight into synchronous defoaming with planetary centrifugal force and high negative pressure.
Actual‑test Performance Demonstration
Measured Processing Results for Six Typical Materials
Slurry + Powder |
Adhesive |
Hydrogen‑energy Materials |
Adhesive |
Substrate + Filler |
Adhesive + Ceramic Powder |
Actual‑test Effect Comparison
Comparison of Material Status Before and After Pressurized Debubbling
| Material Type | Pre‑treatment Status | After RX4‑600 Treatment |
| Polarizer OCA Optical Adhesive | Numerous bubbles inside adhesive, uneven light transmission and mottling after lamination | Transparent bubble‑free adhesive with uniform light transmission after lamination |
| Component Encapsulant | Dense bubbles inside adhesive, voids formed in encapsulation layer after curing | Dense void‑free adhesive for complete and reliable encapsulation layer |
| Medical Bonding Adhesive | Internal bubbles, bonding‑surface defects impairing biocompatibility | Dense adhesive with intact bonding surface and qualified biocompatibility |
* Internal laboratory test data. Actual improvement varies with material formulation. Contact sales for real‑world customer cases.
